radarTOUCH

for ultra large interactive surfaces
extremely versatile
touchless and direct touch interaction
reliable and long-lasting
outdoor proof

radarTOUCH

Q: How much does a radarTOUCH cost?

Pricing varies based on your specific requirements. Get in touch with us for a customized offer that fits your needs!

Q: Where and how can I purchase the radarTOUCH?

As a manufacturer, we only work with resellers. So, if you are not an end customer, you are welcome to buy from us. In some countries we have distributors who can support you locally. If you are an end customer, we would be happy to recommend partners in your area who can provide you with the best possible support. Please contact us .

Q: How will my goods be shipped (DE, EU, Asia, GB, USA, Canada, other?

We work all over the world. We can either send your goods with known carriers or have them ready for collection. Of course, we provide the necessary export accompanying documents for non-EU countries.

Q: Where do I find the manual?

You can find the manual in the download area .

Q: Ist the radarTOUCH suitable for Multi-TOUCH?

The radarTOUCH is a device for very large areas and can recognise over 250 touch points at the same time. However, the radarTOUCH is best suited for interactions with large gestures.

Q: What „resolution“ do I need for touch capabilities?

Since the radarTOUCH is used for very large areas and can also be installes further away from the image, it is not always easy to precisely touch very small points. A touch point should therefore not be smaller than 5x5cm.

Q: Which technology is used?

The radarTOUCH is a rotating scanner thas uses class 1 laser to create an invisible curtain in front of an image. The touch technology is infrared laser.

Q: How can we implement interactive solutions?

We can suggest the ideal solution for your project. You then only need a content producer to program your interactive application according to your requirements.

Q: Is object recognition possible with the radarTOUCH?

No, object recognition is not possible with radarTOUCH .

Q: I’m looking for inspiration, which interactive solutions can be implemented?

The radarTOUCH is an extremely versatile device. Big screens, shopping windows, LED walls, fog screens, etc. Whrerever you have an image, you can make it interactive with the radarTOUCH, regardless oft he technology.

Coming soon: radarTOUCH NEO – Smaller, Faster, Better.
A more compact, faster and enhanced version is on its way.

radarTOUCH has been designed for multitouch applications which exceed common screen sizes. The system is perfectly suitable to realise interaction with any kind of screen or floor, transforming DV LED walls, rear projection screens, LCDs or any other surface into an interactive experience.

At its core, radarTOUCH uses an infrared laser to create an invisible curtain, defining a two-dimensional interaction space that covers a large area with a single unit. For even larger setups, multiple radarTOUCH systems can be combined using the radarSTITCHER software extension, seamlessly expanding the interactive zone. Additionally, the radarTRACK extension enables precise tracking of up to four individuals, further enhancing interactive experiences.

Details

Trade show

Event

Retail

Broadcast

Corporate

Museum

Key features

Made in germany

CE

Easy adjustment

Outdoor

Rental proof

Robust

Models in detail

Find a suitable radarTOUCH for your application below. If you need further information, please check the FAQ or contact us.

radarTOUCH NEO

Specifications

Model numbers
RTouch-NEO	radarTOUCH NEO

Optical data
Measurement radius	0.08 - 25 m 7 m at 1.8% remission 15 m at 10% remission 25 m at 90% remission
Angular range	max. 180°
Angular resolution	0.01°
Scanning rate	40 Hz
Transmitter	Infrared laser, wave length = 905 nm
Response time	at least 25 ms [corresponds to 1 scan]
Flatness of detection plane	+/- 0,2°

Electrical data
Voltage supply	+24 VDC
Power consumption	< 5.5 W at 24 V

Mechanical data
Housing	Zinc die-cast, plastic
Weight	0.56 kg
Dimensions	80 x 80 x 85 mm [plus connections and cables]

Enviromental data
Storing temperature	-30°C to +60°C
Operating temperature	-30°C to +60°C
Relative humidity	< 95% non-condensing

Certification
Protection class [IEC 60529]	IP65
Laser class	Class 1 [according to IEC 60825-1:2014]
Protection class [IEC 61140]	III‚ protective extra-low voltage

Accessories
Standard Mounting	RTOUCH-NEO-STD
Deluxe Mounting	RTOUCH-NEO-DLX-CLP50 (for 50mm pipe mount) RTOUCH-NEO-DLX-CB (for direct ceiling mount)

Warranty
Warranty	24 months

radarTOUCH

Specifications

Model numbers
RTouch-500ME	radarTOUCH original
RTouch-500ME-LT	radarTOUCH light version
RTouch-500ME-HE	radarTOUCH with heating for outdoor applications
RTouch-500ME-HE-LT	radarTOUCH light version with heating for outdoor applications

Optical data
Measurement radius	approx. 25 m‚ equals 50 m in width
Angular range	max. 180°
Angular resolution	0.36°
Scanning rate	25 scans/s or 40 ms/scan
Transmitter	infrared laser diode, laser class 1 [EN 60825], wave length = 905 nm, P max = 15 W, pulse duration: 3 ns
Average output power	12 μW

Detection fields
Object size	> 20 mm at distance of 4 m \| > 100 mm at distance of 15m
Response time	at least 40 ms [corresponds to 1 scan]

Electrical data
Voltage supply	+24 VDC +20 %/- 30 %
Overcurrent protection	fuse 2.5 A semi time-lagin the switching cabinet
Current consumption	approx. 1 A [use power supply with min. 2A] \| approx. 4 A [RTouch-500ME-HE]
Power consumption	< 75 W at 24 V including the outputs
Overvoltage protection	overvoltage protectionwith protected limit stop

Mechanical data
Housing	diecast aluminium‚ plastic
Weight	2.3 kg
Dimensions	140 mm x 168 mm x 167 mm

Enviromental data
Temperature RTouch-500ME	0 °C to +50 °C [operating]‚ -20 °C to +50 °C [storing]
Temperature RTouch-500ME-HE	-20 °C to +50 °C [operating]‚ -20 °C to +50 °C [storing]

Certification
Protection class	IP65
Laser class	1 [acc. to EN 60825-1 and21 CFR 1040.10 with Laser Notice No. 50]
VDE safety class	III‚ protective extra-low voltage
Certifications	CE‚ CDRH‚ c UL US
Standards applied	IEC 60947-5-2‚ UL 508

Accessories
Standard Mounting	RTouch-TH-STD-V2
Deluxe Mounting	RTouch-TH-DLX-V2

Warranty
Warranty	24 months

Visual Details

Downloads

Datasheets

Drawings

Manual

Manual -- radarTOUCH

Others

Why work with us

German engineering

20+ years of experience

Multitouch pioneers

Trustworthy B2B partner

Quick reaction time

Products on-stock

Operating worldwide

Interdisciplinary experts

Contact us

Your contact person

Teodora Neustädter

Director Sales

We speak

Deutsch
English
Español
Français
Italiano
عربيش
Русский
Românește

Our top-selling products

EVO frame series

The newest frame generation is the EVOlution of the very well known earlier frame series. The system has been redesigned...

primeTOUCH flat

primeTOUCH flat revolutionises the world of IR touchscreens. It works as precisely and robust as known from primeTOUCH series combined...

Universal LED Stacking

The LED stacking from EXACT offers a stable modular system that can be easily attached to the various LED modules...

TITAN

With the new TITAN display lift system, large displays and LED walls can be set up easily and safely.

GhosT-OLED

GhosT-OLED offers the possibility for image presentation as well as the transparency to see objects that are placed behind.

radarTOUCH

radarTOUCH was designed for contact-free multi touch applications which exceed common screen sizes.

FAQ

Do you have any additional questions? Don't hesitate to contact us.

General

How much does a radarTOUCH cost?

Where and how can I purchase the radarTOUCH?

How will my goods be shipped (DE, EU, Asia, GB, USA, Canada, other?

Where do I find the manual?

Specific

Ist the radarTOUCH suitable for Multi-TOUCH?

What „resolution“ do I need for touch capabilities?

Which technology is used?

How can we implement interactive solutions?

Is object recognition possible with the radarTOUCH?

I’m looking for inspiration, which interactive solutions can be implemented?

Which technical and creative partners do we need for implementation?

The radarTOUCH works over TUIO (tuio.org) which is a standard communication protocol between software and interactive hardware. Make sure that your application is created in a way that is compatible with TUIO. For many years now, software partners have created divers applications, some oft hem offering basic functions and are very simple to use. But they can of course also offer the whole range of content creation required by complex projects. Contact us for recommendation.

What are the advantages of the radarTOUCH over the competion?

Operating

Can you also install the radarTOUCH outside?

Do I need special fittings for hanging?

Is radarTOUCH suitable for every exposure situation?

Do I need a special power supply?

Is there an extended warranty?

Can the system operate 24/7?
